- Model:
- JSGE400
- Crusher type:
- Counterattack crusher
- Broken object:
- Plastic bottle
- Product alias:
- scraper blades
- Product use:
- Broken PE, PP
- Crushing capacity:
- 250 kg/h
- Screw diameter:
- 1 mm
- Crusher chamber caliber:
- 410*235 mm
- Tool holder rotation diameter:
- 180 mm
- Number of fixed knives:
- 2 把
- Number of moves:
- 3 把
- Motor power:
- 7.5 KW
- Overall dimension:
- 1330*840*1390 mm
- Weight:
- 600 kg
Foshan Jinsui company production of
plastic film crusher, PE beverage bottle crusher blade sharp chopping fast, can be crushed recovery system, broken material through cyclone separator sent to the designated location.
Plastic crusher is suitable for recycling plastic waste, can be used for plastic bottles, plastic woven silk, woven bags, plastic net rope, film, shoes, sheets, plastic plates, plastic pipes, medicinal materials, food and other crushing, can crush nylon, resin, PVC, TPR, polypropylene polyethylene, high and low pressure carbon, rubber and other plastics.This machine is steel plate welded structure, directly driven by V-belt or reducer. The hopper, sieve holder, upper and lower boxes are of separate structure, allowing free movement and convenient material cleaning. The base is connected by screws. Depending on the different crushing materials, hopper can choose to adopt double-layer sound-reducing moving knife triangular symmetrical inclined distribution, fixed knife three-point inclined arrangement, low resistance, high efficiency. Tool installation design can be adjusted telescopically, after use blunt can be used for many times more grinding, low cost. Can provide mechanical feeding, automatic conveying discharge device, long plastic profiles, pipe crushing attached device.
Then the information of the film crusher is:
model
Model |
Diameter of crushing (mm)
Crushing chamber |
Crushing capacity (KG/H)
Crushing ability |
fixed knife
Stationary cutter |
rotary knife
Rotary cutter |
Power |
Outline size (CM)
L*W*H
Dimension |
suttle
KG |
| |
|
|
|
|
KW |
HP |
|
|
| JSGE400 |
410 235 |
100-150 |
2 |
3 |
7.5 |
10 |
103 84 139 |
500 |
| JSGE600 |
610 320 |
200-250 |
4 |
6 |
15 |
20 |
132 111 183 |
1100 |
| JSGE800 |
815 470 |
350-400 |
4 |
6 |
22/30 |
30/40 |
173 149 230 |
2000 |
PE, PP and other thin film materials suitable for crushing recovery; For thin wax material crushing and unique design of scissors knife holder structure, more conducive to improving work efficiency. Optional suction fan, storage bucket composed of film crushing recovery system can give full play to the recovery efficiency.
